CPU | Rockchip RK3399 dual core Cortex-A72+ quad core Cortex-A53 CPU |
GPU | ARM Mali-T860MP4 GPU |
Deposit | LPDDR4 2G/4G optional |
Built-in storage capacity | EMMC 16G/32G/64G optional |
Display interface | LVDS interface (single, 6-bit dual, 8-bit dual). Supports a maximum resolution of 1920x1080, support 7"-84" display |
EDP screen interface, Maximum resolution 4K |
Screen voltage | Support 3.3V/5V/12V optional |
Network | With RJ45 interface, support 10/100/1000 Ethernet |
Support 4G PCIE interface |
With WIFI & BT module, support Wi-Fi 802.11a / b / g / n / ac protocol. Support BT 5.0 |
Image rotation | Support 0 degree, 90 degrees, 180 degrees, 270 degrees manual/automatic rotation, support gravity sensing function |
Real Time Clock | External real-time clock power supply battery |
Interface device | Support MIPI camera x2 |
USB HOST x 3 (support usb camera@500W usb printer, U disk, mouse, keyboard and standard USB peripherals), 1x USB3.0 |
3x UART/(2 UART, 1 SPI), support external serial device (NFC module, printer, card reader, etc.) |
TF card, maximum support 64GB |
Class D amplifier: 5W*2 8 ohms, support microphone |
HDMI 2.0 output |
Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A, 3GPP format |
Video | Supports H.264, MPEG2, VP6, VP8, MVC and other video formats. Online videos such as YouTube, up to 4K, HTML5 video playback, Flash 10.1 playback |
Picture | Support JPG, BMP, PNG, GIF and other image formats to browse and support rotation/image enlargement |
Power Adapter | Input: AC100-240V.50-60HZ, Output: DC12V/3A |
