CPU | Rockchip RK3588 octa-core 64-bit size core architecture，4*Cortex-A76 + 4*Cortex-A55 |
Main frequency | The main frequency of the large core is 2.1GHz, and the main frequency of the small core is 1.7GHz |
GPU | ARM Mali-G610 MC4 |
OpenGL ES 1.1/2.0/3.1/3.2 |
Vulkan 1.1，1.2 |
OpenCL 1.1,1.2,2.0 |
Embedded high-performance 2D image acceleration module |
NPU | 6TOPS AI computing power, triple-core architecture, support int4/int8/int16/FP16/BF16/TF32, enabling various AI scenarios |
Memory | 4GB/8GB/16GB（Up to 32GB）64bit LPDDR4/LPDDR4x |
Built-in storage capacity | EMMC 32G/64G/128G/256G（optional） |
Display interface | HDMI OUT（Up to 8K@60FPS） |
HDMI IN（Up to 8K@60FPS） |
LVDS display interface |
EDP display interface |
MIPI display interface |
Screen voltage | Support 3.3V/5V/12V optional |
Touch screen | Provide I2C interface (can support multi-point resistive touch, multi-point capacitive touch). Support USB multi-point infrared touch, multi-point acoustic wave touch, multi-point optical touch. |
Network | With RJ45 interface, support 10/100/1000M Ethernet. |
Equipped with AP6275S industrial WiFi-6 module SIDO/PCIE dual-channel Bluetooth WiFi module 2T2R 802.11 ax/ac/a/b/g/n Wi-Fi + BT 5.0 Module |
Image rotation | Support 0 degree, 90 degree, 180 degree, 270 degree manual/automatic rotation, support gravity sensing function |
Real Time Clock | Built-in real-time clock powered by battery |
Interface device | Support MIPI interface camera, support 500W pixels |
3 USB HOST 2.0 (4PIN2.0 spacing connectors) | All support usb camera@500W usb printer, U disk, mouse, keyboard, standard usb peripherals |
2 USB HOST3.0 (standard interface) |
1 full-featured Type-C interface (OTG) |
3 sets of serial ports, support external serial device modules (NFC module, printer, card reader, etc.) |
TF card, maximum support 128GB |
Class D power amplifier: default 3W*2 8 ohms, support microphone |
Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A, 3GPP Format |
Video | Support H.265/H.264/AV1/VP9/AVS2 video decoding, up to 8K60FPS Support H.264/H.265 video encoding, up to 8K30FPS |
Picture | Support JPG, BMP, PNG and other image formats to browse and support rotation/slide show/image enlargement functions |
Power Adapter | Input: AC100-240V.50-60HZ, Output: DC12V 3A (positive inside and negative outside) |
