CPU | Rockchip RK3576 Octa-Core 64 bit, 4*Cortex-A72 + 4*Cortex-A53 |
Frequency | Main frequency of the large core: 2.2GHz, Main frequency of the small core: 1.8GHz |
GPU | ARM Mali-G52 MC3 |
OpenGL ES 1.1/2.0/3.2 |
Vulkan 1.2 |
OpenCL 2.1 |
NPU | 6TOPS AI computing power, three core architecture, supports int4/int8/int16/FP16/BF16/TF32, empowering various AI scenarios |
RAM | 2GB/4GB/8GB 32bit LPDDR4/LPDDR4x |
Memory | EMMC 32G/64G/128G/256G optional |
Display interface | HDMI IN（Up to 4K@60FPS） |
LVDS display interface (optional with MIPI) |
MIPI display interface (optional with LVDS) |
EDP display interface |
Display voltage | Supports 3.3V/5V/12V optional(LVDS) |
TP | Provide I2C interface (can support multi-point resistive touch, multi-point capacitive touch). Support USB multi-point infrared touch, multi-point acoustic touch, multi-point optical touch. |
Network | RJ45 port, support 10/100/1000M Ethernet |
Equipped with WiFi&BT module, supporting Wi Fi 802.11a/b/g/n/ac protocol. Supports BT5.0 |
Image rotation | Support 0 degrees, 90 degrees, 180 degrees, 270 degrees manual/automatic rotation, support gravity sensing function |
RTC | External real-time clock power supply battery |
Interfaces | Support MIPI interface camera, up to 500W pixels |
3个USB HOST 2.0 (4PIN 2.0 spacing connection seat) | All support USB camera @500W USB printer, U disk, mouse, keyboard and other standard USB external devices |
1个USB HOST 2.0 (4PIN 2.0 spacing connection seat) |
1个USB HOST3.0 (Standard A interface) |
1个USB HOST2.0 (Standard A interface) |
One full-function Type-C interface (OTG) |
3pcs serial ports, support external serial device modules (NFC module, printer, card reader, etc.) |
TF card，up to128GB |
4G module supporting mipi PCIE interface (default EC20) |
Class D amplifier: 3W* 2pcs 8Ω, support microphone |
Audio format | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP |
Video format | Decoding support 4K@120fps H.265/H.264/AV1/VP9/AVS2 Encoding support 4K@30fps H.264/H.265 Encoding and decoding support 4K@30fps MJPG |
Image Format | Support JPG, BMP, PNG and other image formats browse and support rotation/slide play/image magnification function. |
Power supply | Input: AC100-240V.50-60Hz, Output: DC12V 3A (internally positive and externally negative) |
