CPU | Rockchip RK-PX30 Quad-core Cortex-A35 Mali-G31 MP2 GPU |
Frequency | 1.5GHz |
RAM | DDR3 1G/2G Optional (Lable 1GB) |
ROM | EMMC 8GB/16G/32G/64G Optional（Lable 8GB） |
Display interface | LVDS interface (single, 6-bit dual, 8-bit dual). Support maximum resolution 1920x1080, support 7"-84" display |
EDP Interface |
MIPI Interface |
Screen voltage | 3.3V/5V/12V optional |
Touch Screen | Provide I2C interface (can support multi-point resistive touch, multi-point capacitive touch). Support USB multi-point infrared touch, multi-point acoustic wave touch, multi-point optical touch. |
Internet | With RJ45 interface, support 10/100 Ethernet. |
Equipped with Wifi & BT module, supporting Wi-Fi 802.11b/g/n protocol. Support BT4.0 (option WIFI 802.11 a/b/g/n/ac 5G&2.4G) |
Image rotation | Support 0 degree, 90 degree, 180 degree, 270 degree manual/auto rotation, support gravity sensor function |
Real Time Clock | External real-time clock power supply battery |
Interfaces | Support MIPI interface camera, up to 500W pixels |
3 USB HOST (secondary board), support usb camera @500W usb printer, U disk, mouse, keyboard, standard USB peripherals) |
3 groups of serial ports. Support external serial port device module (3G module, NFC module, printer, card reader, etc.) |
SD card, maximum support 32GB |
Class D power amplifier: 3W*2 8 ohms, support microphone |
Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP格式 |
Video | Support 4K 60fps H.265,H.264,VC-1, MPEG-1/2/4, VP8 video decoding; support 1080P H.265/VP8 video encoding |
Image | Support JPG, BMP, PNG and other image format browsing and support rotation/slide show/picture zoom function |
Adapter | Input: AC100-240V.50-60HZ， Output： DC12V /3A |
