CPU | Rockchip RK3399 dual-core Cortex-A72+ quad-core Cortex-A53 CPU |
GPU | ARM Mali-T860MP4 GPU |
Run and save | LPDDR4 4G |
Built-in storage capacity | EMMC 8GB/16G/32G/64G optional (label 16GB) |
Display interface | LVDS interface (MIPI and LVDS can only choose one or the other) |
EDP screen interface |
MIPI screen interface (MIPI and LVDS can only choose one or the other) |
Screen voltage | Support 3.3V/5V/12V optional |
Touch screen | Provide I2C interface (multi-point capacitive touch) Support USB multi-point capacitive touch, multi-point infrared touch, multi-point acoustic wave touch, multi-point optical touch |
Network | With RJ45 interface, support 10/100 Ethernet |
Equipped with Wifi & BT module, supporting Wi-Fi 802.11a/b/g/n/ ac protocol. Support BT4.0 |
Image rotation | Support 0 degree, 90 degree, 180 degree, 270 degree manual/auto rotation, gravity sensor function (optional) |
Real Time Clock | External real-time clock power supply battery |
Interface device | Support MIPI interface camera |
6 USB HOST (support usb camera@500W usb printer, U disk, mouse, keyboard and standard usb peripherals) |
2 groups of UART, 1 group of SPI or 1 group of UART, 2 groups of SPI. Support external serial devices (NFC module, printer, card reader, etc.) |
SD card, maximum support 64GB |
Class D power amplifier: 3W*2 8 ohms, support microphone |
HDMI 2.0 output |
Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP Format |
Video | Support H.264, MPEG2, VP6, VP8, MVC and other video formats 2160P@24FPS decoding. YouTube and other online videos, up to 4K, HTML5 video playback, Flash 10.1 playback |
Picture | Support JPG, BMP, PNG, GIF and other image formats to browse and support rotation/image enlargement function |
Power Adapter | Input: AC100-240V.50-60HZ, output: DC12V 3A |
