CPU | RockChipRK3188 quad core Cortex-A9 quad core GPU Mail-400 @ 533MHz |
Frequency | 1.6 GHz |
RAM | DDR3 1G/2G Optional |
Built-in storage capacity | NAND FLASH 8GB/16G/32GOptional (label 8GB) |
DIF | LVDS interface（Single, 6-way, 8-way dual).Support maximum resolution 1920x1080, support 7 "-82" display. |
Onboard backlight | Support 3.3V/5V/12V Optional |
Touch screen | Provide I2C interface (can support multi-point resistance touch, multi-point capacitive touch). Support USB multi-point infrared touch, multi-point sound saw touch, multi-point optical touch. |
Network | Have RJ45 interface, support Ethernet. |
Have wifi & BT module,support Wi-Fi 802.11b/g/nprotocol.Support BT3.0/BT4.0 |
With wifi & BT module, support Wi-Fi 802.11b / g / n protocol. Support BT3.0 / BT4.0 |
Image rotation | Support 0 degree,90 degree,180 degree, 270 degrees manual/automatic rotation, support gravity sensing function. |
Real Time Clock | Built-in real-time clock powered battery |
Interface device | Support DVP interface camera, the maximum support 500W pixels |
Support USB camera |
3 USB HOST (1 motherboard, 2 small board), 1 USB OTG |
1 group serial port. Support external serial device module (3G module, NFC module, printer, card reader, etc.) |
1 group of I2C ports |
SD card, maximum support 32GB |
D class large built-in speaker, 8 oh / 3W |
Support for microphones |
Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP format |
Video | Support H.264, VP8, RV, WMV, AVS, H.263, MPEG4 video formats such as 1080P decoding, YouTube and other online video, up to 1080P, HTML5 video playback, Flash 10.1 play |
Picture | Support JPG, BMP, PNG and other picture formats to browse and support the rotation/slide show/picture zoom |
Power Adapter | Input AC100-240V.50-60HZ, output: DC12V 3A |
